Description:
Top Dog Attachments Manure Fork Grapple: Efficient Cleanup Solution
The Manure Fork Grapple from Top Dog Attachments is a purpose-built attachment designed for efficient cleanup of manure, hay, straw, and light brush. With a large round-tine design, it simplifies post-use cleanup, making it easy to wash down. This versatile grapple comes in three variants, ensuring compatibility with different applications.
Key Features:
-
Versatile Applications:
- Designed for manure, hay, straw cleanup, and light brush clearing.
-
Replaceable Tines:
- Equipped with 1-1/2" 1144 Steel replaceable tines, enhancing durability and longevity.
-
Easy to Wash Design:
- Large round-tine design facilitates easy washing down after use.
-
Variants:
- Available in three variants: 66" Manure Grapple, 72" Manure Grapple, and 78" Manure Grapple.
-
Made in the USA:
- Proudly manufactured in the USA, ensuring quality and craftsmanship.
Specifications:
| Description | 66″ Manure Grapple | 72″ Manure Grapple | 78″ Manure Grapple |
|---|---|---|---|
| Overall Width | 66” | 72” | 78” |
| Overall Height-Closed | 33” | 33” | 33” |
| Overall Height-Open | 54 1/2” | 54 1/2” | 54 1/2” |
| Overall Depth | 45 1/4″ | 45 1/4″ | 45 1/4″ |
| Grapple Openings | 45 1/2″ | 45 1/2″ | 45 1/2″ |
| Depth of Bucket | 34 1/2 “ | 34 1/2 “ | 34 1/2 “ |
| Tines (replaceable) | 1-1/2″ 1144 Steel | 1-1/2″ 1144 Steel | 1-1/2″ 1144 Steel |
| Top Tube | 3 x 3 x 187 | 3 x 3 x 187 | 3 x 3 x 187 |
| Main Body | 1/4″ A36 | 1/4″ A36 | 1/4″ A36 |
| Grapple Arms | 1/2″ Gusseted | 1/2″ Gusseted | 1/2″ Gusseted |
| Cylinders | 2″ Bore | 2″ Bore | 2″ Bore |
| Weight | 812 lbs | 837 lbs | 812 lbs |
Choose the Top Dog Attachments Manure Fork Grapple for a reliable, versatile, and USA-made solution to streamline your cleanup tasks.
